• 433MHz Frequency :The 433MHz frequency ensures a stable and reliable connection between the remote control and the garage door opener.

• Four Key Copy :With four key copies, you can easily replace lost or damaged remote controls without having to purchase a new one.

• Battery-Powered :The remote control is battery-powered, making it easy to install and use without the need for any wiring or electrical work.

• Wireless Remote Control :The wireless remote control allows you to easily open and close your garage door from a distance, making it convenient and efficient.

Product features

(1) Operating frequency: 433.92 MHz

(2) Power supply scheme: DC3V (button battery 2032) power supply.

(3) Standby current: less than 0.15uA.

(4) Good selectivity and spurious radiation suppression capability.

(5) Good local vibration radiation suppression capability.

(6) Temperature range: -20-70°C (-20-70°C) Even in harsh ambient temperatures, it can work normally.

(7) Product size: 60*37.4*11.4 (mm) (including housing).

(8) Product weight: 14.39g (including case).

Function Description

(1) Copy Code Matching Operation

If the remote control has checked the code, it needs to be cleared before the code can be checked. Code matching operation: Press a single button on both the copied remote control and the copy remote control at the same time, until the copy remote control indicator light flashes from fast to steady, and then release the two remote control buttons. Code matching is successful. Follow this method to operate other buttons in sequence until all buttons are copied.

(2) Clear code operation

Simultaneously press and hold the lock and unlock buttons on the copy remote control until the indicator light flashes three times, and then briefly press the unlock button three times to indicate that the code has been cleared successfully (the lock button is held down continuously during this process).

(3) Recovery code operation

Press and hold the mute and ring buttons of the copy remote control simultaneously until the indicator light flashes quickly, and the previously cleared remote control code can be restored.

Note

(1) The working voltage cannot exceed the normal working voltage by 1V.

(2) In environments with high wireless interference, the transmission distance may decrease.

(3) Keep out of reach of children.

(4) Do not use in damp environments, as it may cause damage to the remote control.
